Learn about our ElectroSurgery range & accompanying accessories

Company History: LED SPA

Founded by Aldo Mauti in 1982 in Rome, Italy - LED began with the creation of electrosurgical and physiotherapy equipment distributing primarily in Italy. The company specialises in the design and production of medical electronics. LED is now a global brand servicing over 100 countries across the globe with high-quality electrosurgical products.

StarkMed Product Offerings:

At a glance, you can see the design intent expressed through the retro-aesthetic of the LED electrosurgical units. The colour coding makes it easy to identify the cut & coagulation modes. Each LED Surtron system has been customised to include the essential instruments and accessories in one convenient package. The Surtron 80W, 200W and 400W diathermy systems cover a large spectrum of requirements from simple Office Based Procedures to the complex cases of the Hospital Operating Theatre.

LED Surtron 80



The Italian made LED SURTRON® high-frequency electrosurgical unit which allows Max output power CUT 80 W-250 Ω, cut-coagulation BLEND, superficial coagulation FORCED COAG, deep coagulation in absence of necrosis SOFT COAG and BIPOLAR coagulation. The digital reading of delivered power and the monitoring of operative function guarantees reliable feedback to the user. The connection of the neutral electrode is constantly monitored. The earth plate contact is monitored using a split electrode.

It is possible to control the monopolar output functions (Cut or Coag) at the handle or at the foot switch, this takes away any need to turn away from the surgical field.

Package Includes

  • Reusable Bipolar Forceps
  • Cable for BiPolar Forceps
  • Reusable Monopolar Hand control
  • 10 x Electrode tips (various)
  • Foot Switch
  • Cable for Neutral Electrode
  • Neutral Electrode
  • Power supply cable 2m

Features

  • Max output power CUT 80 W-250 Ω
  • Max output power BLEND 60 W-200 Ω
  • Max output power FORCED COAG 50W-150Ω
  • Max output power SOFT COAG 40 W-100 Ω
  • Max output power BIPOLAR 30 W-100 Ω
  • Working frequency 600 KHz

LED Surtron 400HP



The Italian made LED SURTRON® 400HP can be used to simultaneously perform monopolar and bipolar surgery in application fields which require high precision and reliability.

The high-frequency electrosurgical unit which allows Max output power CUT 400W-300 Ω, cut-coagulation BLEND, monopolar coagulation DEEP, SPEEDY and SPRAY.

The digital reading of delivered power and the monitoring of operative function guarantees reliable feedback to the user. The connection of the neutral electrode is constantly monitored. The earth plate contact is monitored using a split electrode.

It is possible to control the monopoly output functions at the handle as well as the delivery of power output, this takes away any need to turn away from the surgical field.

This is a specialist product made to order which requires a 6 week lead time.

LED Touch 200



The LED SURTRON® TOUCH 200 is a High-Frequency electrosurgical unit (ESU) with Touch Screen suitable for precision monopolar, bipolar and micro-surgery.

SURTRON® TOUCH can supply HF operative power for a programmable time as short as hundreds of seconds.

The device allows pure CUT, cut-coagulation BLEND, incision with reduced production of eschar ENHANCED, superficial coagulation FORCED COAG, deep coagulation in absence of necrosis SOFT COAG, bipolar CUT and COAG. The digital reading of the delivered power and the overseeing through the microcontroller of the operational functions, assure the absolute reliability of the conditions of work.

The connection of the neutral electrode is constantly monitored. Safety control of patient/plate contact using a split neutral electrode. It is possible to control the output functions via the handle or foot control.

Features

  • Working frequency 360 kHz
  • RF power pulse emission time 10ms-30sec
  • RF power pulse interval 1-30

Package Includes

  • Touch 200 ESU
  • Reusable Monopolar Hand Control Pencil
  • Waterproof Dual Pedal Foot Switch
  • Monopolar electrode tips
  • Patient Return Cable
  • Reusable Patient Return Electrode
  • AC Power cable

Erbe Electrosurgery Accessories

If you'd like to increase your electrosurgery equipment range, take a look at our offerings from Erbe.

Erbe BiPolar Forceps



Erbe Reusable Bipolar Forceps in a straight configuration with fine tip, blunt tip and various lengths available.
3 different types to choose from;
  • Bipolar forceps; 15 cm; 0.7 mm fine tip
  • Bipolar forceps; 10.5 cm; 0.5 mm fine tip
  • Bipolar forceps; 14.5 cm; 1 mm blunt tip

Selecting an 'option' will change the picture.

To view the entire ERBE BiPolar catalogue please click here.

Erbe Cable - BiPolar Forceps



Erbe Connection cable for BiPolar Forceps - 4m. This connection cable is suitable for Erbe, Valleylab and other units. The cable connects to the generator using a 28mm, 2-pin connection. The BiPolar Forceps connect via a European Flat Plug connection.

Erbe Patient Plate

Erbe NESSY Omega Split Patient Return Plate. NESSY® (Neutral Electrode Safety System), integrated in the VIO® series, checks whether the split-pad return electrode is correctly applied over the entire area. The current flowing through the two contact surfaces are continuously equalised. If the return electrode is not applied properly there is a current asymmetry. This allows the pad to be applied irrespective of the direction of the operative site.

  • A contact surface of 85cm2
  • High current densities and partial heating are largely avoided,
    despite the small return electrode area
  • Positioning irrespective of surgical site
  • Suitable for adults and children
  • Skin-compatible contact layer

The plates are supplied in a box of 50.
